CW2

The C-WRAP is made of eco-friendly materials and comes in two sizes with selectable features. The design simplifies installation and prevents damage to ceilings. Can be surface mounted or hung from chains with included hardware.



• Field-adjustable wattages: 2 Ft: 22/17/11W (3,000/2,250/1,500lm) 4 Ft: 44/33/22W (6,000/4,500/3,000lm)
• Field-adjustable CCT: 3500/4000/5000K
• Microwave occupancy sensor battery backup options available.
• UL Listed for damp locations
• 0-10V dimming
• 5-Year, no compromise warranty

Spec Sheets

Info

Wattage	11W/17W/22W
Lumen	1,503-3,040
Color Temp.	3500K-5000K
Efficacy	125.8-133.3 lm
CRI	84-85
L70 Lifespan	100,000
Reflector	Refractive Lens
Lens	Diffused Polymethyl Methacrylate (PMMA)
Mounting	Surface mount. Can be mounted with v-hooks (ordered separately).
Housing	Sustainable, bio-composite resin manufactured with coffee chaff, waste seashells, and recycled plastic.
Finish	Naturally occurring, beige, speckled pattern

Additional Info

Electrical Driver 22W: Class P, Constant Current, 120-277V, 50/60 Hz, 120V: 0.20A, 208V: 0.11A, 240V: 0.10A, 277V: 0.09A 17W: Class P, Constant Current, 120-277V, 50/60 Hz, 120V: 0.15A, 208V: 0.10A, 240V: 0.08A, 277V: 0.07A 11W: Class P, Constant Current, 120-277V, 50/60 Hz, 120V: 0.10A, 208V: 0.07A, 240V: 0.06A, 277V: 0.05A Power Factor 99.8% at 120V, 96.6% at 277V THD 1.29% at 120V, 9.1% at 277V Dimming Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
