Broadcast with Live Deck 2
Live Deck (Android-based) transmits real-time full HD video to your TV, computer, and/or multiple cell phones s via Ethernet, USB-A, HDMI interface, or livedeck generated WiFi. Adopted with upgraded image transmission technology, its anti-interference ability is times greater than Live Deck 1. It supports 2.4GHz/5.8GHz/900MHz working frequency.
Multi-Band Strong Transmission
Based on the SkyLink 2.0 image transmission system, Live Deck 2 can communicate with aircraft via 2.4GHz/5.8GHz/900MHz working frequencies. Adopted with a three-in-one antenna, the performance of the transmission, anti-EMI, low latency have improved greatly.
Advanced Signal Anti-Interference System
Do not let interference hinder your mission success. SkyLink 2.0 provides an updated and advanced anti-interference capability with its advanced algorithms and frequency hopping, you can always obtain consistent information with uninterrupted operation/workflow in difficult working environments.
Stream Anywhere
The Live Deck 2 supports multiple video output options, including HDMI, USB-A, and Ethernet, enabling users to view clear visuals to the device of their choosing.
5-Hour Battery Life
Powered by a 6200mAh lithium battery, Live Deck 2 can run for up to 5 hours on a single charge. Once depleted, juice up anywhere using the micro USB port or a portable battery pack.
Specifications:
| Weight | 424.5g |
| Dimensions | 152*111*23.2mm (antennas folded) 223.9*152*23.3mm (antennas unfolded) |
| Ingress Protection | IP43 |
| Operating Frequency | 902-928MHz（FCC） 2.400-2.4835GHz 5.725-5.850GHz（Non-Japan） 5.650-5.755GHz（Japan Only） |
| Transmitter Power (EIRP) | 900MHz: FCC<=33dBm 2.4GHz: FCC/NCC<=33dBm; CE/MIC/SRRC/KC<=20dBm 5.8GHz/5.7GHz: FCC/SRRC/NCC<=33dBm; KC<=20dBm; CE<=14dBm |
| Max Transmission Distance (unobstructed, free of interference) | 12km |
| Operating time | 5h |
| Operating Current/Voltage | 1.3A/3.85V (not connected to smartphone) |
| Battery Type | Li-Po |
| Battery Capacity | 6200mAh |
| Rated Power | 5 W |
| Operating Temperature | 14°F~104°F (-10°C~40°C) |
| Operating Humidity | 95%RH |
| HDMI | 1080p@60 fps |
| Ethernet | 100M |
| Supported Aircrafts | EVO II Pro V3 EVO II Dual 640T V3 EVO II RTK Series V3 EVO II Enterprise V3 |
